The Sonos Ray is your perfect starter soundbar
Experience clearer, more powerful sound than ever before possible by a small standalone soundbar.
Tuned to perfection
Trueplay tuning technology adapts the sound for the unique acoustics of your space so content always sounds just the way it should.
Supported iOS device required
Zero-stress setup
Go from unboxing to unbelievable sound in minutes. Just plug in the power cable, connect Ray to your TV's optical port, and open the Sonos app. It does most of the work for you.
Listen here, there, everywhere
Play your way with speakers in every room. Enjoy TV in the living room while you stream music in the bedroom, and group your system for whole-home listening.
Tailor your home theatre experience with the Sonos app
Turn on Speech Enhancement for even clearer dialogue when characters whisper or the music swells. Turn on Night Sound to reduce the intensity of loud effects when you don't want to disturb anyone else at home.
Better together
Mix and match speakers to build the system you want. Enjoy listening all around your home, and reconfigure your setup any time.
Amplifiers
All four Class-D digital amplifiers have been fine-tuned to the soundbar's unique acoustic architecture.
Tweeters
Two tweeters create a crisp high-frequency response.
Midwoofers
Two high-efficiency midwoofers ensure faithful playback of mid-range frequencies and solid bass.
Bass Reflex System
Proprietary low-velocity port design minimises distortion and rounds out low-end frequencies.
Adjustable EQ
Use the Sonos app to adjust bass, treble, and loudness.
Trueplay
This software measures the acoustics of the room then fine-tunes the soundbar. Supported iOS device required.
Speech Enhancement
Turn this setting on in the Sonos app to boost voice frequencies and clarify dialogue.
Night Sound
Turn this setting on in the Sonos app to reduce the intensity of loud sounds and increase the level of quieter sounds.
Home Theatre Audio Formats
Stereo PCM, Dolby Digital 5.1* and DTS Digital Surround* (*This is not an indication of a licenced decoder.) The Sonos app's Now Playing screen will display what type of audio is being decoded.
WiFi
Connect to WiFi with any 2.4 GHz 802.11/b/g/n broadcast-capable router.
Optical
Connect to your TV's optical output with the included cable.
Ethernet
10/100 port for hardwiring to your router
Infrared (IR) Receiver
Syncs the soundbar with your TV remote for streamlined control
Voltage
Auto-switching 100-240V 50/60Hz AC universal input
CPU
Quad Core
1.4 GHz A-53
Memory
1GB SDRAM
4GB NV
Apple AirPlay 2
Works with AirPlay 2 on Apple devices iOS 11.4 and higher
Mounting
M5 threaded mounting socket
Dimensions
Height: 71 mm
Width: 559 mm
Depth: 95 mm
Weight
1.95 kg
Colours
Black, White
Controls
Use the capacitive touch controls on the product to adjust the volume, play, pause, skip, and replay.
LEDs
Lights on the product indicate connection and mute status.
Where should I place Ray?
All of the acoustic components face forward for maximum versatility. Ray can be mounted to the wall, placed on top of furniture, or tucked into an enclosed shelf of your TV stand. We recommend at least 5 mm of space between the edges and any surrounding surfaces.
Which Sonos speakers work as surrounds?
A matching pair of the following speakers will work as surrounds: Era 300, Era 100, Sonos One (including SL), Sonos Five, Play:1, Play:3, and Play:5 (Gen 2). You can also use Sonos Amp to power in-wall, in-ceiling, or other passive speakers as surrounds.
Can I connect a subwoofer to Ray?
Ray is compatible with all generations of Sonos Sub. The soundbar will not work with a third-party subwoofer.
How do I know if my TV has optical output?
Most TVs from major manufacturers have an optical connection. You should be able to find a port on the back of your TV, labelled either Optical Audio, TOSLINK, Digital Audio Out, or something similar. This information should also be available in your TV's manual.
Can I stream using Bluetooth?
Ray does not have Bluetooth connectivity but streams audio content over your WiFi network. Internet access allows you to stream higher fidelity audio over greater distances, group or pair Sonos speakers, and more.
Can I use voice control with Ray?
You can use Amazon Alexa or Google Assistant with a compatible device, such as Sonos One, Amazon Echo Dot, or Google Nest Mini. While streaming with AirPlay 2, you can use Siri on your iOS device to control Apple Music.
Can I use the Sonos S1 Controller app with Ray?
Ray requires the latest generation of the Sonos app, Sonos S2.
