Rectangular coaxial speaker, recessed ceiling, 2xBass/Medium Polyglass of 13cm, inverted dome tweeter, 120W/8Ohms

₦ 1,064,199.15 1064199.15 NGN ₦ 1,064,199.15

$ 620.66

Not Available For Sale

  • Product Type
  • Nominal Impedance
  • Frequency Response
  • Weight
  • Sensitivity (1W/1m)
  • Minimal impedance
  • Recommended amplifier power
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Product Type: 2-way-in--ceiling
Nominal Impedance: 8 Ω
Frequency Response: 55Hz
Weight: 7.2kg
Sensitivity (1W/1m): 92dB
Minimal impedance: 4.6Ω
Recommended amplifier power: 25 - 120W
Brand: Focal

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

100 ICLCR5

The 100 ICLCR5 in-ceiling loudspeakers can be highlighted for their acoustics performances and compact design.

PERFECT ACOUSTICS

100 ICW5, 100 ICW6 and 100 ICW8, 100 IC6ST and ICLCR5 offer three position switch (-3dB, 0 dB, +3 dB) to adjust the treble according to the acoustic environment (reverberation on windows or on tiles for example). Two loudspeakers can be connected to the same amplifier.

HI-FI OR HOME CINEMA

All the products from the 100 Series can be used to reinforce classic Hi-Fi systems, particularly the loudspeakers from the Chorus 700 series, for those looking for discreet, high-quality Home Cinema system.

INSTALLATION IN HUMID ENVIRONMENTS

Tropicalisation is used on Polyglass membranes to allow the installation in humid environments, such as bathrooms.

IN-CEILING 2-WAY LOUDSPEAKERS

The 100 ICLCR5 in-ceiling loudspeakers can be highlighted for their acoustics performances and compact design. Here is the masterpiece for your Home Cinema system (in dedicated rooms or living rooms), installed in the ceiling which reinforces classic Hi-Fi loudspeakers or in-wall loudspeakers. It is also ideal for very large rooms without any rear wall nearby. Five possible applications: front left, center or right channels, rear left and rear right channels.

This in-ceiling loudspeaker has a new aluminum inverted dome adjustable tweeter, more compact, improving the sound dispersion. Its two drive units are also equipped with a new Polyglass cone (5” – 13 cm).  A new crossover improves the off-axis listening and avoids the “shower effect”. Its three position switch allows choosing the left, center or right channels to adjust the treble level.


This product can be installed everywhere thanks to a compact design with the speaker driver’s basket and chassis being redesigned as one only piece, frameless square and circular front grilles.

The 100 Series brings an unexpected musicality to your home with ease.  Let yourself be surprised by the technology behind this product, an efficient design and ideal features for an easy use at this price.

HI-FI OR HOME CINEMA

All the products from the 100 Series can be used to reinforce classic Hi-Fi systems, particularly the loudspeakers from the Chorus 700 series, for those looking for discreet, high-quality Home Cinema system.

INSTALLATION IN HUMID ENVIRONMENTS

Tropicalisation is used on Polyglass membranes to allow the installation in humid environments, such as bathrooms.

PERFECT ACOUSTICS

100 ICW5, 100 ICW6 and 100 ICW8, 100 IC6ST and ICLCR5 offer three position switch (-3dB, 0 dB, +3 dB) to adjust the treble according to the acoustic environment (reverberation on windows or on tiles for example). Two loudspeakers can be connected to the same amplifier.

Type

2-way in-ceiling

Drivers

2 x 5" (13cm) Polyglass woofers, 1" (25mm) inverted dome tweeter, 8" (21cm) Polyglass passive radiator

Sensitivity(2.83V/1m)

92dB

Frequency response (+/-3dB)

65Hz - 23kHz

Low frequency point (-6dB)

55Hz

Nominal impedance

8 Ω

Minimal impedance
4.6 Ω
Recommended amplifier power
25 - 120W
External dimensions (HxWxD)
1315/16"x1315/16"x55/16" (354x354x150mm)
Cut-Out diameter (HxW)
1215/16"x1215/16" (328x328mm)
Depth from wall
6" (152mm)
Net weight (with front grille)
11.6lbs (5.3kg)
Packing dimensions (WxDxH)
161/16"x 161/16"x71/2" (408x408x190mm)
Total weight (with packaging)
15.8 lbs (7.2kg)
