  2. 100 ICW5

100 ICW5

https://www.ced.africa/web/image/product.template/179/image_1920?unique=0f675dc
(0 review)

Enceinte coaxiale encastrable murale/plafond, Grave/Medium Polyglass de 13cm, tweeter à dôme inversé, 100W/8Ohms

₦ 343,044.54 343044.54 NGN ₦ 343,044.54

$ 194.58

Not Available For Sale

  • Product Type
  • Nominal Impedance
  • Frequency Response
  • Weight
  • Sensitivity (1W/1m)
  • Minimal impedance
  • Recommended amplifier power
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Product Type: In-wall/In-celling - 2-way coaxial
Nominal Impedance: 8 Ω
Frequency Response: 65Hz-23kHz
Weight: 1.45kg
Sensitivity (1W/1m): 88dB
Minimal impedance: 7.3Ώ
Recommended amplifier power: 15-100W
Brand: Focal

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

100 ICW5

The 100 ICW5 loudspeaker which is dedicated to home delivers an amazing sound quality and has a compact design.

PERFECT ACOUSTICS

100 ICW5, 100 ICW6 and 100 ICW8, 100 IC6ST and ICLCR5 offer three position switch (-3dB, 0 dB, +3 dB) to adjust the treble according to the acoustic environment (reverberation on windows or on tiles for example). Two loudspeakers can be connected to the same amplifier.

HI-FI OR HOME CINEMA

All the products from the 100 Series can be used to reinforce classic Hi-Fi systems, particularly the loudspeakers from the Chorus 700 series, for those looking for discreet, high-quality Home Cinema system.

INSTALLATION IN HUMID ENVIRONMENTS

Tropicalisation is used on Polyglass membranes to allow the installation in humid environments, such as bathrooms.

IN-WALL/IN-CEILING 2-WAY COAXIAL LOUDSPEAKER

The 100 ICW5 loudspeaker which is dedicated to home delivers an amazing sound quality and has a compact design. The product is aimed at small to medium sized rooms and for three types of use: distributed systems (hallways, living rooms…), stereo systems (bedrooms, kitchens…) and Home Cinema systems (in dedicated rooms or living rooms). This product is suitable for every room in the house, even in humid environment such as bathrooms. It can be used in-wall or in-ceiling. This coaxial loudspeaker has a new aluminum inverted dome tweeter, more compact, improving sound dispersion.

It is also equipped with a new Polyglass cone (51/8” – 13 cm). A new crossover improves the off-axis listening and avoids the “shower effect”. This product can be installed everywhere thanks to a compact design with the speaker driver’s basket and chassis being redesigned as a single piece and also to square and circular magnetic front grilles, frameless.

The 100 Series line brings an unexpected musicality to your home with ease. Let yourself be surprised by the technology behind this product, an efficient design and ideal features for an easy use.

I-FI OR HOME CINEMA

All the products from the 100 Series can be used to reinforce classic Hi-Fi systems, particularly the loudspeakers from the Chorus 700 series, for those looking for discreet, high-quality Home Cinema system.

INSTALLATION IN HUMID ENVIRONMENTS

Tropicalisation is used on Polyglass membranes to allow the installation in humid environments, such as bathrooms.

PERFECT ACOUSTICS

100 ICW5, 100 ICW6 and 100 ICW8, 100 IC6ST and ICLCR5 offer three position switch (-3dB, 0 dB, +3 dB) to adjust the treble according to the acoustic environment (reverberation on windows or on tiles for example). Two loudspeakers can be connected to the same amplifier.

Type

In-wall/In-celling 2-way coaxial

Drivers

8" (21cm) Polyglass Midbass. 1" (25mm) AI inverted dome Tweeter

Sensitivity (2.83V/1m)

90dB

Frequency response (+/-3dB)

53Hz-23kHz

Low frequency point (-6dB)

40Hz

Nominal impedance

8Ώ

Minimal impedance

6,9Ώ

Recommended amplifier power

25-150W

External dimensions (Ø/Depth)

93/4"x43/8" (248x111mm)

Cut-Out diameter

813/16" (224mm)

Depth from wall

43/16" (107mm)

Net weight (with front grille)

3.86lbs (1.75kg)

Packing dimensions (WxDxH)

123/16"x123/16"x71/4" (310x310x185mm)

Total weight (with packaging)

4.73lbs (2.60kg)
