100 IW6

https://www.ced.africa/web/image/product.template/181/image_1920?unique=0f675dc
(0 review)

In-wall 2-Way Loudspeaker. The 100 IW6 loudspeaker which is dedicated to home delivers an amazing sound quality and has a compact design.

₦ 445,270.97 445270.97000000003 NGN ₦ 445,270.97

$ 259.69

Not Available For Sale

  • Product Type
  • Nominal Impedance
  • Frequency Response
  • Weight
  • Sensitivity (1W/1m)
  • Minimal impedance
  • Recommended amplifier power
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Product Type: In-wall-2-way
Nominal Impedance: 8 Ω
Frequency Response: 48Hz
Weight: 1.85kg
Sensitivity (1W/1m): 89dB
Minimal impedance: 7.2Ω
Recommended amplifier power: 25-120W
Brand: Focal

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

100 IW6

The 100 IW6 loudspeaker which is dedicated to home delivers an amazing sound quality and has a compact design.

PERFECT ACOUSTICS

100 IW6 and 100 IWLCR5 have adjustable tweeter level offer three position switch (-3dB, 0 dB, +3 dB) to adjust the treble according to the acoustic environment (reverberation on windows or on tiles for example). Two loudspeakers can be connected to the same amplifier.

HI-FI OR HOME CINEMA

All the products from the 100 Series can be used to reinforce classic Hi-Fi systems, particularly the loudspeakers from the Chorus 700 series, for those looking for discreet, high-quality Home Cinema system.

INSTALLATION IN HUMID ENVIRONMENTS

Tropicalisation is used on Polyglass membranes to allow an installation in humid environments, such as bathrooms for example.

IN-WALL 2-WAY LOUDSPEAKER

The 100 IW6 loudspeaker which is dedicated to home delivers an amazing sound quality and has a compact design. This product is aimed at small to medium sized rooms and for three types of use: distributed systems (hallways, living rooms), stereo systems (bedrooms, kitchens) and Home Cinema systems (in dedicated rooms or living rooms). The product is suitable for every room in the house, even in humid environments such as bathrooms.

This in-wall loudspeaker has a new aluminum inverted dome adjustable tweeter, more compact, improving sound dispersion. It is also equipped with a new Polyglass cone (61/2” – 16.5 cm).

A two positions switch allows adjusting the trebles and the mid-bass for a better acoustic performance.

The 100 Series brings an unexpected musicality to your home with ease. Let yourself be surprised by the technology behind this product, an efficient design and ideal features for an easy use at this price.

HI-FI OR HOME CINEMA

All the products from the 100 Series can be used to reinforce classic Hi-Fi systems, particularly the loudspeakers from the Chorus 700 series, for those looking for discreet, high-quality Home Cinema system.

EASY INSTALLATION

Installation is an important criterion: the three mounting brackets with optimized grips ensure a quick and easy installation. This system prevents screws from falling out when dismantling the product. The installation time is kept to a minimum. The 100 Series products have a shallow mounting depth which makes the installation much easier.

PERFECT ACOUSTICS

100 IW6 and 100 IWLCR5 have adjustable tweeter level offer three position switch (-3dB, 0 dB, +3 dB) to adjust the treble according to the acoustic environment (reverberation on windows or on tiles for example). Two loudspeakers can be connected to the same amplifier.

Type

In-wall 2-way

Drivers

61/2" (16.5cm) Polyglass Midbass 1" (25mm) AI inverted dome Tweeter

Sensitivity (2.83V/1m)

89dB

Frequency response (+/-3dB)

60Hz-23kHz

Low frequency point (-6dB)

48Hz

Nominal impedance

8Ώ

Minimal impedance

7,2Ώ

Recommended amplifier power

25-120W

External dimensions (Ø/Depth)

113/4"x711/16"x35/8" (298x195x92mm)

Cut-Out diameter

103/4"x611/16" (273x170mm)

Depth from wall

37/16" (88mm)

Net weight (with front grille)

4,1lbs (1.85kg)

Packing dimensions (WxDxH)

131/2"x97/16"x415/16" (343x240x126mm)

Total weight (with packaging)

4.98lbs (2.25kg)
