100 IWLCR5

https://www.ced.africa/web/image/product.template/186/image_1920?unique=0f675dc
(0 review)

The 100 IWLCR5 loudspeakers which are dedicated to home audio can be highlighted for their acoustics performances and compact design. These products are aimed at small to medium sized rooms and for three types of use: distributed systems (hallways, living rooms…), stereo systems (bedrooms, kitchens…) and Home Cinema systems (in dedicated rooms or living rooms).

₦ 692,202.71 692202.71 NGN ₦ 692,202.71

$ 366.90

Not Available For Sale

  • Product Type
  • Nominal Impedance
  • Frequency Response
  • Weight
  • Sensitivity (1W/1m)
  • Minimal impedance
  • Recommended amplifier power
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Product Type: D'appolito In-wall 2-way
Nominal Impedance: 8 Ω
Frequency Response: 43Hz
Weight: 3.45kg
Sensitivity (1W/1m): 90,5dB
Minimal impedance: 3.8Ω
Recommended amplifier power: 25-120W
Brand: Focal

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

100 IWLCR5

The 100 IWLCR5 loudspeakers which are dedicated to home audio can be highlighted for their acoustics performances and compact design.

PERFECT ACOUSTICS

100 IW6 and 100 IWLCR5 have adjustable tweeter level offer three position switch (-3dB, 0 dB, +3 dB) to adjust the treble according to the acoustic environment (reverberation on windows or on tiles for example). Two loudspeakers can be connected to the same amplifier.

HI-FI OR HOME CINEMA

All the products from the 100 Series can be used to reinforce classic Hi-Fi systems, particularly the loudspeakers from the Chorus 700 series, for those looking for discreet, high-quality Home Cinema system.

INSTALLATION IN HUMID ENVIRONMENTS

Tropicalisation is used on Polyglass membranes to allow an installation in humid environments, such as bathrooms for example.

IN-WALL 2-WAY D’APPOLITO LOUDSPEAKERS

The 100 IWLCR5 loudspeakers which are dedicated to home audio can be highlighted for their acoustics performances and compact design. These products are aimed at small to medium sized rooms and for three types of use: distributed systems (hallways, living rooms…), stereo systems (bedrooms, kitchens…) and Home Cinema systems (in dedicated rooms or living rooms).

This in-wall loudspeaker has a new aluminum inverted dome adjustable tweeter, more compact, improving the sound dispersion. It is also equipped with a new Polyglass cone (51/8” – 13 cm).

This LCR (Left, Centre, Right) loudspeaker can be used horizontally, as a center channel for a Home Cinema system. It has a three-position switch which allows choosing the left, center or right channels to adjust the levels according to the acoustic environment.

This product can be installed everywhere thanks to a compact design with the speaker driver’s basket and chassis being redesigned as one only piece, frameless square and circular front grilles. Let yourself be surprised by the technology behind this product, an efficient design and ideal features for an easy use at this price.

HI-FI OR HOME CINEMA

All the products from the 100 Series can be used to reinforce classic Hi-Fi systems, particularly the loudspeakers from the Chorus 700 series, for those looking for discreet, high-quality Home Cinema system.

EASY INSTALLATION

Installation is an important criterion: the three mounting brackets with optimized grips ensure a quick and easy installation. This system prevents screws from falling out when dismantling the product. The installation time is kept to a minimum. The 100 Series products have a shallow mounting depth which makes the installation much easier.

PERFECT ACOUSTICS

100 IW6 and 100 IWLCR5 have adjustable tweeter level offer three position switch (-3dB, 0 dB, +3 dB) to adjust the treble according to the acoustic environment (reverberation on windows or on tiles for example). Two loudspeakers can be connected to the same amplifier.

Type

D'appolito In-wall 2-way

Drivers

2x5" (13cm) Polyglass Midbass 1" (25mm) AI inverted dome Tweeter

Sensitivity (2.83V/1m)

90,5dB

Frequency response (+/-3dB)

55Hz-23kHz

Low frequency point (-6dB)

43Hz

Nominal impedance

8Ώ

Minimal impedance

3.8Ώ

Recommended amplifier power

25-120W

External dimensions (Ø/Depth)

175/16"x613/16"x33/8" (440x173x86mm)

Cut-Out diameter

165/16"x513/16" (415x147mm)

Depth from wall

31/4" (83mm)

Net weight (with front grille)

3.89lbs (2.90kg)

Packing dimensions (WxDxH) 193/16"x811/16"x411/16" (487x220x119mm)

193/16"x811/16"x411/16" (487x220x119mm)

Total weight (with packaging)

7.6lbs (3.45kg)
