AV AMPLIFIER ASTRAL 16

https://www.ced.africa/web/image/product.template/284/image_1920?unique=0f675dc
(0 review)

The design has a simple elegance, with a large (4.3in) central TFT display that provides general information, three control buttons, a sizable volume dial, and a power switch.

₦ 37,857,036.12 37857036.12 NGN ₦ 37,857,036.12

$ 20,066.01

Not Available For Sale

  • Product Type
  • Weight
  • Power Consumption
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Product Type: 16 channel audio-video processor and amplifier
Weight: 23.0kg
Power Consumption: 100V to 240V
Brand: Focal

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

ASTRAL 16

Astral 16 draws the very best out of high-fidelity and in-wall/in-ceiling loudspeakers by perfectly coordinating all the components within a sensational Home Cinema installation.

ALL AUDIO FORMATS

Astral 16 covers all audio formats: Dolby Atmos®, DTS:X™, Auro-3D® etc.

Equipped with technology that allows adjustments based on room characteristics (Room calibration, with Dirac Live®) and delivered with a calibrated measurement microphone, Astral 16 can be fine-tuned to suit all possible acoustical environments and desires.

ENDLESS CONFIGURATION OPTION

Astral 16 comes with an app available on the App Store (via iPad) to drive the system you want room by room, as well as technical support (Remote Monitoring) for equipment diagnostics at any time.

COMPATIBILITY

Astral 16 is compatible with Control4, Crestron, Elan, Savant and RTI.

It benefits from the potential of these leading interfaces to provide remote control over your entire system.

AUDIO-VIDEO PROCESSOR AND AMPLIFIER

Like any true conductor who draws the best out of his orchestra, Astral 16 draws the very best out of high-fidelity and in-wall/in-ceiling loudspeakers by perfectly coordinating all the components within a sensational Home Cinema installation.

Integrating a Class D Pascal Audio amplifier, Astral 16 has 16 channels, of which 12 are amplified and 4 are pre-amplified (balanced XLR outputs) and dedicated entirely to audio (filtering, equalization, bass management, etc.).

This rock-solid foundation is your official invitation to an immersive journey through images and sound of unrivaled quality (sampling frequency supported up to 192 kHz).

ALL AUDIO FORMATS

Astral 16 covers all audio formats: Dolby Atmos®, DTS:X™, Auro-3D® etc.

Equipped with technology that allows adjustments based on room characteristics (Room calibration, with Dirac Live®) and delivered with a calibrated measurement microphone, Astral 16 can be fine-tuned to suit all possible acoustical environments and desires.

COMPATIBILITY

Astral 16 is compatible with Control4, Crestron, Elan, Savant and RTI.

It benefits from the potential of these leading interfaces to provide remote control over your entire system.

ENDLESS CONFIGURATION OPTION

Astral 16 comes with an app available on the App Store (via iPad) to drive the system you want room by room, as well as technical support (Remote Monitoring) for equipment diagnostics at any time.





Type

16 channel audio-video processor and amplifier


Main features

Compatible formats

Dolby Atmos® / DTS:X™ / Auro-3D®


Room Calibration

Powered by Dirac Live® : target curve editable from 20Hz to 20kHz for all channels (including subwoofers), phase correction full bandwidth 20Hz-20kHz on all channels (including subwoofers)


"Remote Monitoring" fonction


Multichannel / Surround Processing

Output channels Decoding / upmixing channels Input sampling rate supported Stereo downmix Bass management Multi-subwoofer channels Multi-way crossover 20 Parametric EQ per channel

16 up to 16 channels up to 192kHz fully flexible Unlimited (6-12-18-24-36-48dB/oct filter slopes)

HDMI
HDMI inputs HDMI outputs (mirror) Supported video format High Dynamic Range Color Space and Subsampling Deep Color Max resolution supported HDMI
7: HDMI 2.0 / HDCP 2.2 1: HDMI 2.0 / HDCP 2.2 (with eARC) 2: HDMI 2.0 / HDCP 2.2 Up to 4K UHD HDR10 / HLG 4:4:4, 4:2:2, 4:2:0 12 bpc 4K 60fps 4:4:4 8bpc 3D / 4K / eARC
Audio Inputs
Digital input Analog stereo inputs
3 x coaxial, 3 x optical 4 x RCA inputs
Amplified Audio Outputs
Amplified main outputs Analog main outputs, balanced Stereo downmix outputs, balanced Technology Amplified channels Continuous power output, per channel, à 0.1%THD 3 channels driven simultaneous, 6 channels driven simultaneous, 12 channels driven simultaneous Continuous power output, per channel, à 1%THD 3 channels driven simultaneous, 6 channels driven simultaneous, 12 channels driven simultaneous, SNR (P-rated) THD (from 1W to P-rated -1dB)
12 4 x XLR 2 x XLR Class D 12 8Ω / 4Ω / 2.7Ω 200W / 400W / 650W 200W / 350W / 350W 200W / 300W 8Ω / 4Ω / 2.7Ω 250W / 500W / 725W 250W / 500W / 500W 250W / 300W 110dB <0.03%
Set-Up Management
Configurable multi-theater management Configurable audio zones management Unlimited Theater and audio zones listening presets Backup and restore of set-up Firmware update via USB/network

Control Inputs / Outputs
USB type A Ethernet Output trigger control IR remote ports, in/out
2 4 (out) 1 / 1
Control / Custom Installation
Web-based product configurator TCP/IP API based control Focal Remote iPad control application Home automation Front panel display
Crestron, Control4, Savant, RTI home automation TFT 4.3"
Power Supply
Voltage range Type Range selection
100V to 240V SMPS Universal
Supplied with
Calibrated measurement microphone and tripod, Dirac Live license, 32.9ft (10m) cable with infra-red captor, mounting kit

Dimensions & weight
Net weight – with stands (kg/lbs) Net weight – with accessories for Rack (kg/lbs) Dimensions with stands (h x w x d) (cm/inches)
20.0 / 44.1 23.0 / 50.7 19.10 x 47.90 x 49 / 7.52 x 18.86 x 19.29
