GA201

https://www.ced.africa/web/image/product.template/765/image_1920?unique=91a0875
(0 review)

Class-D Mini Amplifier 2x125W RMS @2Ω 1/6 1 Rack Unit

₦ 490,571.36 490571.36 NGN ₦ 490,571.36

$ 286.11

Not Available For Sale

  • Product Type
  • Material
  • Weight
  • Output Power
  • Connections
  • Brand
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Product Type: 2-Channel Class D Amplifier
Material: Stainless Steel
Weight: 1kg
Output Power: 2x120W RMS @2ohm
Connections: Input: 3,5mm Jack, DC Jack Output: 3,5mm Jack Link Out, 2x Phoenix connectors
Brand: KGear, KGear

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

GA201

The KGEAR GA201 Mini Power Amplifier is a tiny yet powerful audio solution designed to deliver 2x125W RMS even at a 2 Ohm load.

DSP Integration and Remote Programmability

Select models in the GA line, such as the GA46 and GA43, come with integrated DSP processors and are remotely programmable through Powersoft™ ArmoníaPlus software. This enables you to adjust settings, load presets, and optimize your audio system from a distance, ensuring peak performance at all times.

Expandable Audio Systems

Several GA models, like the GA201, offer expandability through linking capabilities, allowing you to connect multiple amplifiers together for increased speaker coverage. This feature ensures that the GA amplifiers can adapt to different audio system configurations, providing tailored solutions for any installation.

This tiny and essential amplifier is able to deliver 2x125W RMS to a load as low as 2 Ohm, providing an extremely flexible and reliable solution to sound distribution in small sized environments.

Up to 6 amplifiers can be linked together to expand the total amount of speakers thanks to a 3,5mm jack connector.

Designed for permanent installations such as retail shops, restaurants, hotels, pubs, bars and residential, GA201 is perfect for driving KGEAR GF speakers and GS6 subwoofer.

The compact modular design allows to fit up to 6 GA201 elements (12 channels) into 1 rack unit with G-RACKMINI accessory.

GENERAL
Input Channels: 2
Output Channels: 2
Max Output Power per Channel: 125 Watt (RMS EIAJ @ 2 ohm 26VDC)
Minimum Impedance: 2Ω
Operating Voltage: 12-24 VDC 4A
Power Supply Operating Voltage: 85-245 VAC (external power supply included)
AC Current: 1A Nominal
Width: 72mm (2,83in)
Height: 42mm (1,65in)
Depth: 131mm (5,16in)
Rack adapter: G-RACKMINI

AUDIO I/O

Analog unbalanced I: 3.5mm Jack, stereo
Analog power O: 2x Phoenix connectors
Line O: 3.5mm Jack, stereo (Link Out)



GA201 - Data Sheet


GA201 - User Manual


Kgear_Amp-to_Speaker_Matching_Table_Rev20220530
