GA41

https://www.ced.africa/web/image/product.template/766/image_1920?unique=8e41b35
(0 review)

Networked Class-D Power Amplifier With Dsp 4x150W RMS @4Ω 2IN-4OUT 1/3 2 Rack Unit

₦ 3,634,177.68 3634177.68 NGN ₦ 3,634,177.68

$ 2,061.36

Not Available For Sale

  • Colour
  • Product Type
  • Impedance
  • Material
  • Weight
  • Output Power
  • Connections
  • Brand
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Colour: Black
Product Type: 4-Channel Class D
Impedance: 4Ω
Material: Stainless Steel
Weight: 2.6kg
Output Power: 4x150 W @4ohm
Connections: 2x Combo jack-XLR female line 1x RJ45 2x SpeakOn 4 pole
Brand: KGear, KGear

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

GA41

The KGEAR GA41 is a compact 4-channel high-efficiency Class D amplifier featuring a Powersoft™ power module and DSP processor.

DSP Integration and Remote Programmability

Select models in the GA line, such as the GA46 and GA43, come with integrated DSP processors and are remotely programmable through Powersoft™ ArmoníaPlus software. This enables you to adjust settings, load presets, and optimize your audio system from a distance, ensuring peak performance at all times.

Expandable Audio Systems

Several GA models, like the GA201, offer expandability through linking capabilities, allowing you to connect multiple amplifiers together for increased speaker coverage. This feature ensures that the GA amplifiers can adapt to different audio system configurations, providing tailored solutions for any installation.

Compact 4-channel high efficiency class D amplifier featuring Powersoft™ power module and DSP processor.

Delivering up to 150W RMS per channel at 4 ohms, this amplifier is a very flexible solution for all those small to medium applications.

Thanks to its modular design, 3 elements of GA41 can fit into 2 rack units with a dedicated accessory (G-RACK).

Remotely programmable with Powersoft™ ArmoníaPlus software through Ethernet connection, GA41 has 4 selectable presets that can be adjusted to your needs and recalled by a physical button on the rear panel.

Designed for high performance applications permanent installations such as restaurants, bars and pubs, auditoriums, conference rooms, residential.

GENERAL
Input Channels: 2
Output Channels: 4
Max Output Power per Channel: 150W (RMS EIAJ Single Channel Driven @ 4 ohm)
Minimum Impedance: 4Ω
Internal DSP: 28-bit data path with 56-bit inner processing
Operating Voltage: 85-264 VAC
AC Current: 7A Nominal
Width: 145mm (5,71in)
Height: 90mm (3,54in)
Depth: 418mm (16,46in)
Rack adapter: G-RACK

AUDIO I/O

Analog balanced I: 2 x Combo jack-XLR female line
Analog power O: 2 x Speakon (4 pole)

AUDIO CONTROLS

Volume potentiometer | RJ45 connector | DSP can be remotely controlled via an Ethernet connection through Powersoft ArmoniaPlus Software



GA41 - Datasheet


GA41 - Default Presets


KGEAR_GA41 GA43 GA46 User Manual


CB Report GA41/41L GA43/43L GA46/46L


Kgear_Amp-to_Speaker_Matching_Table_Rev20220530
