GA43L

https://www.ced.africa/web/image/product.template/770/image_1920?unique=8e41b35
(0 review)

Class-D Power Amplifier 4x750W RMS @4Ω 4IN-4OUT 1/3 2 Rack Unit

₦ 3,544,119.39 3544119.39 NGN ₦ 3,544,119.39

$ 1,878.55

Not Available For Sale

  • Colour
  • Product Type
  • Impedance
  • Material
  • Weight
  • Output Power
  • Connections
  • Brand
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Colour: Black
Product Type: 4-Channel Class D
Impedance: 4Ω
Material: Stainless Steel
Weight: 3.6kg
Output Power: 4x750 W RMS @4ohm
Connections: Input: 4x XLR balanced Output: 2x SpeakOn 4 pole
Brand: KGear, KGear

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

GA43L

GA43L is a compact 4-channel high efficiency class D amplifier featuring Powersoft™ power module, capable of delivering up to 4x750W per channel at 4 ohm or 2x1500W at 8 ohm / 100V*.

DSP Integration and Remote Programmability

Select models in the GA line, such as the GA46 and GA43, come with integrated DSP processors and are remotely programmable through Powersoft™ ArmoníaPlus software. This enables you to adjust settings, load presets, and optimize your audio system from a distance, ensuring peak performance at all times.

Expandable Audio Systems

Several GA models, like the GA201, offer expandability through linking capabilities, allowing you to connect multiple amplifiers together for increased speaker coverage. This feature ensures that the GA amplifiers can adapt to different audio system configurations, providing tailored solutions for any installation.

GA43L is a compact 4-channel high efficiency class D amplifier featuring Powersoft™ power module, capable of delivering up to 4x750W per channel at 4 ohm or 2x1500W at 8 ohm / 100V*.

Thanks to its modular design, 3 elements of GA43L can fit into 2 rack units with a dedicated accessory (G-RACK).

Designed for high performance applications both for rental and permanent installations such as touring, auditoriums, transportation facilities, houses of worship, stadiums, theme parks and clubs.

GENERAL
Input Channels: 4
Output Channels: 4
Max Output Power per Channel: 750W (RMS EIAJ Single Channel Driven @ 4 ohm)
Minimum Impedance: 4Ω
Max Output Power (Bridge mode*): 2x1500W @ 8Ω
High Impedance Power: 2x1500W @ 100V (bridge mode*)
Operating Voltage: 85-264 VAC
AC Current: 7A Nominal
Width: 145mm (5,71in)
Height: 90mm (3,54in)
Depth: 418mm (16,46in)
Rack adapter: G-RACK

AUDIO I/O

Analog balanced I: 4x XLR female line
Analog power O: 2x Speakon (4 pole)



KGEAR_GA41 GA43 GA46 User Manual


CB Report GA41/41L GA43/43L GA46/46L


Kgear_Amp-to_Speaker_Matching_Table_Rev20220530


KGEAR - Presets Pack
