Networked Class-D Power Amplifier With Dsp 4x1500W RMS @4Ω Or 100V 2IN-4OUT 1/3 2 Rack Unit

₦ 5,634,394.92 5634394.92 NGN ₦ 5,634,394.92

$ 3,286.08

Not Available For Sale

  • Colour
  • Product Type
  • Impedance
  • Material
  • Weight
  • Output Power
  • Connections
  • Brand
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Colour: Black
Product Type: 4-Channel Class D
Impedance: 4Ω
Material: Stainless Steel
Weight: 3.8kg
Output Power: 4x1500 W RMS @4ohm
Connections: 2x Combo jack-XLR female line 1x RJ45 2x SpeakOn 4 pole
Brand: KGear, KGear

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

GA46

Introducing the KGEAR GA46 Amplifier: Unparalleled Power and Versatility for Demanding Applications

DSP Integration and Remote Programmability

Select models in the GA line, such as the GA46 and GA43, come with integrated DSP processors and are remotely programmable through Powersoft™ ArmoníaPlus software. This enables you to adjust settings, load presets, and optimize your audio system from a distance, ensuring peak performance at all times.

Expandable Audio Systems

Several GA models, like the GA201, offer expandability through linking capabilities, allowing you to connect multiple amplifiers together for increased speaker coverage. This feature ensures that the GA amplifiers can adapt to different audio system configurations, providing tailored solutions for any installation.

Our top of the line compact 4-channel class D amplifier featuring Powersoft™ power module.

Delivering up to 1500W RMS per channel at 4 ohm, this amplifier is able to drive 70V/100V distributed speaker lines without needing any additional transformer*.

Thanks to the modular design, up to 3 units of GA46 (totally 12 channels) fit into 2 rack units with G-RACK accessory.

Remotely programmable with Powersoft™ ArmoníaPlus software through Ethernet connection, GA46 has 4 selectable presets that can be adjusted to your needs and recalled by a physical button on the rear panel.

Designed for the most demanding applications for rental and permanent installations in touring and events, auditoriums, transportation facilities, houses of worship, stadiums, theme parks and clubs.

GENERAL
Input Channels: 2
Output Channels: 4
Max Output Power per Channel: 1500W (RMS EIAJ Single Channel Driven @ 4 ohm)
Minimum Impedance: 4Ω
High Impedance Speaker Lines: 70V - 100V(-2dB) *
Internal DSP: 28 bit data path with 56 bit inner processing
Operating Voltage: 85-264 VAC
AC Current: 10A Nominal

AUDIO I/O

Analog balanced I: 2 x Combo jack-XLR female line
Analog power O: 2 x Speakon (4 pole)

AUDIO CONTROLS

Volume potentiometer | RJ45 connector | DSP can be remotely controlled via an Ethernet connection through Powersoft ArmoniaPlus Software
PHYSICAL OVERVIEW
Width: 145mm (5,71in)
Height: 90mm (3,54in)
Depth: 418mm (16,46in)
Rack adapter: G-RACK
