  2. GA46L

GA46L

https://www.ced.africa/web/image/product.template/772/image_1920?unique=8e41b35
(0 review)

Class-D Power Amplifier 4x1500W RMS @4Ω Or 100V 4IN-4OUT 1/3 2 Rack Unit

₦ 4,760,068.07 4760068.07 NGN ₦ 4,760,068.07

$ 2,523.06

Not Available For Sale

  • Colour
  • Product Type
  • Impedance
  • Material
  • Weight
  • Output Power
  • Connections
  • Brand
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Colour: Black
Product Type: 4-Channel Class D
Impedance: 4Ω
Material: Stainless Steel
Weight: 3.6kg
Output Power: 4x1500 W RMS @4ohm
Connections: Input: 4x XLR balanced Output: 2x SpeakOn 4 pole
Brand: KGear, KGear

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

GA46L

Introducing KGEAR GA46L Amplifier: Supreme Power and Adaptability for the Most Demanding Applications

DSP Integration and Remote Programmability

Select models in the GA line, such as the GA46 and GA43, come with integrated DSP processors and are remotely programmable through Powersoft™ ArmoníaPlus software. This enables you to adjust settings, load presets, and optimize your audio system from a distance, ensuring peak performance at all times.

Expandable Audio Systems

Several GA models, like the GA201, offer expandability through linking capabilities, allowing you to connect multiple amplifiers together for increased speaker coverage. This feature ensures that the GA amplifiers can adapt to different audio system configurations, providing tailored solutions for any installation.

Our most powerful compact 4-channel class D amplifier featuring Powersoft™ power module.

Delivering up to 1500W RMS per channel at 4 ohm, this amplifier is also able to drive 70V/100V distributed speaker lines without needing any additional transformer*.

Thanks to its modular design, up to 3 elements of GA46L (totally 12 channels) fit into 2 rack units with a dedicated accessory (G-RACK).

Designed for the most demanding applications for rental and permanent installations such as touring and events, auditoriums, transportation facilities, houses of worship, stadiums, theme parks and clubs.

GENERAL
Input Channels: 4
Output Channels: 4
Max Output Power per Channel: 1500W (RMS EIAJ Single Channel Driven @ 4ohm)
Minimum Impedance: 4Ω
High Impedance Speaker Lines: 70V - 100V(-2dB) *
Operating Voltage: 85-264 VAC
AC Current: 10A Nominal
Width: 145mm (5,71in)
Height: 90mm (3,54in)
Depth: 418mm (16,46in)
Rack adapter: G-RACK

AUDIO I/O

Analog balanced I: 4x XLR female line
Analog power O: 2x Speakon (4 pole)
