Active 4" High Performance Stainless Steel Full Range Speaker / Mini Array Element 100W Black Color

₦ 1,120,485.45 1120485.45 NGN ₦ 1,120,485.45

$ 593.91

Not Available For Sale

  • Coverage
  • Colour
  • Product Type
  • Max SPL
  • Rated Power
  • Nominal Impedance
  • Material
  • Frequency Response
  • Weight
  • IP Rating
  • Output Power
  • Power Consumption
  • Connections
  • Brand
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Coverage: V. 90° | H. 90°
Product Type: Active loudspeaker
Max SPL: 116 dB (peak)
Rated Power: 140 W
Nominal Impedance: 4 Ω
Material: Stainless Steel
Frequency Response: 150 Hz - 20 kHz (-6dB)
Weight: 1,2 kg
IP Rating: IP64 (G-IPCAP1 accessory required)
Output Power: 100W @ 2Ω (24V power)
Power Consumption: 30W Rated Load 1/8 Max Power
Connections: 2x Phoenix connector (4-pin euroblock), Balanced Line in, Mute contact Power out, 24V DC IN (power supply not included)
Brand: KGear, KGear

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

GH4A

Introducing GH4A, a high-performance, ultra-compact active point source satellite speaker that delivers exceptional sound quality and coverage in a small and versatile package.

Weather-Resistant Construction

The GH line's rugged durability is due in part to its weather-resistant construction. The compact stainless steel cabinets are built to withstand the rigors of touring and permanent installation, providing added peace of mind.

Compact and Portable Design

The GH line's compact and portable design makes it easy to transport and set up for any event or installation.

Whether you need to cover a small room or a large stadium, the GH speakers are designed to provide even sound coverage and control.

Scalability

All of the speakers in the GH family can be combined to create a cluster of line array elements or a complete sound system, allowing for scalability and flexibility in any audio application.

Introducing GH4A, a high-performance, ultra-compact active point source satellite speaker that delivers exceptional sound quality and coverage in a small and versatile package. Featuring a 4" full-range driver with a dual-coil neodymium magnet, GH4A is capable of delivering powerful and clear sound even in challenging acoustic environments.


GH4A is equipped with 2 Phoenix connectors (4-pin Euroblock) that host a balanced line input, a mute contact, and an auto ON/OFF switch with selectable thresholds. Additionally, it has a power output that allows you to connect another KGEAR speaker or passive subwoofer from the KGEAR series and drive them with its onboard amplifier, with a minimum load of 4Ω.


In addition, GH4A comes with an adjustable wall mount bracket (GF-WALL) for easy installation and positioning.

The unique cabinet design of GH4A ensures much lower emission on the back side of the speaker, improving sound control and preventing loss of energy. The robust stainless-steel enclosure is designed to withstand even the harshest conditions, with an IP64 rating obtainable when using the not included accessory G-IPCAP1, ensuring durability and reliability.

GH4A can be combined with other units to create an array and obtain even higher performance. With its flexibility and compactness, GH4A is a great choice for fixed installation in a wide variety of sound reinforcement applications, from restaurants to hospitality, transportation, corporate, broadcast, theaters, houses of worship, and residential settings.


Experience exceptional sound quality, flexibility, and durability with the GH4A active point source satellite speaker, perfect for any setting.

GENERAL
Power handling: 140W
Impedance: 4-16Ω (selectable)
Frequency range: 120hz – 20khz (-10db average)
Maximum SPL(1): 122dB (peak)
Coverage: v.90° - H.90°
TRANSDUCERS
4” Wide range driver with neodymium magnet

AUDIO I/O

GH4
Analog power I: 4-pin Euroblock (Phoenix MCV 1,5mm/4G-3,81 BK)

GH4A
2x Phoenix connector (4-pin euroblock)
Balanced Line in
Mute contact
Power out
24V DC IN (power supply not included)
Auto ON-OFF threshold switch

PHYSCIAL OVERVIEW

Width: 112mm (4.41in)
Height: 112mm (4.41in)
Depth: 94mm (3.7in)
Weight: 1,2kg (2.65lbs)
Material: stainless steel
Color: Black (GH4, GH4A) / White (GH4W, GH4AW)
Rating: IP64 (G-IPCAP1 accessory required)
