GM44L

https://www.ced.africa/web/image/product.template/773/image_1920?unique=8e41b35
(0 review)

Analog Audio Matrix 4IN - 4 OUT Stereo w/ AUX IN Mute Contact and Zone EQ 1/3 1 Rack Unit

₦ 916,758.55 916758.55 NGN ₦ 916,758.55

$ 534.67

Not Available For Sale

  • Product Type
  • Connections
  • Brand
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Product Type: 4-Zone Analog Matrix
Connections: Input: 4x Line-In Stereo 3,5mm Jack 1x Aux-In Stereo 3,5mm Jack 1x Dry Contact In 3,5mm Jack 1x 24V DC Power In Output: 4x Line Out Stereo 3,5mm Jack 5x Link Line Out 3,5mm Jack
Brand: KGear, KGear

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

GM44L

The GM44L is a versatile 4-zone analog audio matrix, perfect for managing multi-zone sound distribution in a variety of applications.

DSP Integration and Remote Programmability

Select models in the GA line, such as the GA46 and GA43, come with integrated DSP processors and are remotely programmable through Powersoft™ ArmoníaPlus software. This enables you to adjust settings, load presets, and optimize your audio system from a distance, ensuring peak performance at all times.

Expandable Audio Systems

Several GA models, like the GA201, offer expandability through linking capabilities, allowing you to connect multiple amplifiers together for increased speaker coverage. This feature ensures that the GA amplifiers can adapt to different audio system configurations, providing tailored solutions for any installation.

GM44L is a 4-Zone analog audio matrix that features 4 Stereo Line inputs with gain control, 4 Stereo Line outputs with Treble and Bass adjustment, 4 Zone input selectors and 1 Auxiliary input that can be independently assigned to each zone output and mixed to the selected input channel.

This matrix also has a dry contact input that allows to mute all the inputs except the priority auxiliary input for emergency purposes. More GM44L units can be linked together to increase the number of outputs thanks to 5 Link outputs corresponding to each one of the inputs (including Aux-In).

All the connections are made utilizing 3,5mm Stereo Jack Connectors. GM44L is the perfect preamp combination to our GA201 amplifier as 1 GM44L and up to 4 GA201 amps can be mounted in just 1 Rack Unit space thanks to our G-RACKMINI2 accessory, making it a great solution for multi-zone sound distribution and public address solution for bars and restaurants, hospitality, corporate, conference and residential applications.

GENERAL
Type: 4-Zone Analog Matrix

Inputs: 4x Line-In Stereo 3,5mm Jack
1x Aux-In Stereo 3,5mm Jack
1x Dry Contact In 3,5mm Jack
1x 24V DC Power In

Outputs: 4x Line Out Stereo 3,5mm Jack
5x Link Line Out 3,5mm Jack
CONTROLS
FRONT PANEL
4x Zone Input Selectors
4x Input Signal Monitoring LEDs

TOP PANEL
4x Input Gain Trimmers
4x Output Bass Adjustment Trimmers
4x Output Treble Adjustment Trimmers

BOTTOM PANEL
4x Aux-In Selection Dip Switch
1x Dry Contact Type Dip Switch (NC/NO)
ACCESSORIES
ACCESSORIES INCLUDED
4x 40cm/1,3ft 3,5mm Jack Patch Cable
24VDC Power Supply

ACCESSORIES AVAILABLE
G-RACKMINI2 rack mount accessory for GM44L and GA201
K-AL120 power supply
