Passive System 2x18" Subwoofer + GH412 Co-Axial Stainless Steel Slim Array Black Color

₦ 15,749,960.56 15749960.56 NGN ₦ 15,749,960.56

$ 8,348.22

Not Available For Sale

  • Coverage
  • Colour
  • Product Type
  • Transducers
  • Max SPL
  • Rated Power
  • Nominal Impedance
  • Material
  • Frequency Response
  • Weight
  • IP Rating
  • Connections
  • Brand
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Coverage: V.25° - H.90°
Colour: Black
Product Type: Powered 2x18” sub + 4x12” Slim Array
Transducers: SUB: 2x18” / TOP: 4x12” coaxial with 1” compression driver ferrite magnet
Max SPL: 140 dB
Rated Power: SUB: 3000W / TOP: 1600W
Nominal Impedance: SUB: 4Ω / TOP: 8Ω
Material: SUB: Birch plywood / TOP: Stainless steel
Frequency Response: 30Hz – 20KHz (-6dB average)
Weight: 115,6kg (254.85lbs)
Connections: 2x Speakon NL4
Brand: KGear, KGear

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

GPX

Introducing our top-of-the-line high-performance passive audio system, GPX.

Advanced Systems for Mid-to-Large Applications

The GPXA, GPX, GPZA, GPZ, GP1812A, and GP1812 systems come equipped with a built-in Class-D amplifier and SAT technology, allowing for even greater control over sound dispersion and ensuring precise, uniform sound in large areas. These systems cater to mid-to-large applications, such as public events, live bands, auditoriums, and nightclubs, making them perfect for both rental and permanent installations.

Portable Solutions for Smaller Events

The product range from GP8 to GP12 offers even more portability, with the GP8AB featuring a battery-powered subwoofer for versatility in any setting. Their quick setup and compact design make these systems perfect for small gigs, cocktail parties, and even karaoke sessions at home.

GPX is our top of the line high performance passive system and comprises of a 2x18” subwoofer combined with GH412, our 4x12” coaxial slim array with K-array™ SAT® (Slim Array Technology), PAT® (Pure Array Technology) and a stainless-steel cabinet.

Thanks to its extreme performance and the compact format of the array, this system works in a stack configuration, with the array on top of the subwoofer. It is also possible to fly GH412 with our GH-FLY flybar accessory or place it on the ground with our GH-BASE accessory.

This system can be driven by GPXA active system in a stereo configuration or by GA46 power amplifiers.

Perfect for high SPL outdoor/indoor applications in large venues both for rental and permanent installations for touring, auditoriums, stadia, clubs, theme parks.

User Tip: optimize the cost and combine the system with the active model whether it is for stereo configurations or if need to extend the satellite cluster to form an array.

GENERAL
Power Handling: 1500W subwoofer + 750W satellite
Peak Power: 3000W subwoofer + 1500W satellite
Impedance: 4Ω subwoofer + 8Ω satellite
Frequency Range: 30 Hz - 20 KHz (-6 dB average)
Maximum SPL(1): 140dB (peak)
Continuos SPL: 128dB
Coverage: V.30° - H.90°
TRANSDUCERS
Subwoofer: 2x18” ferrite magnet

Mid High Frequency: 4x12” coaxial with 1” compression driver ferrite magnet

SUBWOOFER

Width: 1035mm (40,75in)
Height: 614mm (24,17in)
Depth: 600mm (23,6in)
Weight: 58kg (127,88lbs)
Material: birch plywood
Rating: IP43

AUDIO I/O

Speakon
SATELLITE
Width: 327mm (12,87in)
Height: 1290mm (50,79in)
Depth: 198mm (7,79in)
Weight: 55,2kg (121,69lbs)
Material: stainless steel
Rating: IP54

ACCESSORIES
GPINM20: M20 pin (included)
K-SPKCABLE15: 15m/49ft Speakon cable (included)
K-SPKCABLE2: 2m/6,6ft Speakon sub to satellite cable (included)
GH-BASE: Floor stacking hardware for GH12/GH412 (optional)
GH-JOINT: Adjustable stacking hardware for GH12/GH412 (optional)
