Active System 2x18" Subwoofer + GH412 Co-Axial Stainless Steel Slim Array 4x1500W Amp Black Color

₦ 20,781,169.27 20781169.27 NGN ₦ 20,781,169.27

$ 12,119.95

Not Available For Sale

  • Coverage
  • Colour
  • Product Type
  • Transducers
  • Max SPL
  • Rated Power
  • Nominal Impedance
  • Material
  • Frequency Response
  • Weight
  • IP Rating
  • Power Consumption
  • Controllers
  • Brand
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Coverage: V.25° - H.90°
Colour: Black
Product Type: Powered 2x18” sub + 4x12” Slim Array
Transducers: SUB: 2x18” / TOP: 4x12” coaxial with 1” compression driver ferrite magnet
Max SPL: 140 dB
Rated Power: SUB: 3000W / TOP: 1600W
Nominal Impedance: SUB: 4Ω / TOP: 8Ω
Material: SUB: Birch plywood / TOP: Stainless steel
Frequency Response: 30Hz – 20KHz (-6dB average)
Weight: 116,6kg (257,06lbs)
Power Consumption: 500W Rated Load (1/8 Max Output Power)
Controllers: Volume potentiometer, RJ45 connector, DSP can be remotely controlled via an Ethernet connection through Powersoft ArmoniaPlus Software
Brand: KGear, KGear

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

GPXA

Introducing our high-performance audio system, GPXA, designed to meet the needs of audio tech enthusiasts who demand the best in sound quality.

Advanced Systems for Mid-to-Large Applications

The GPXA, GPX, GPZA, GPZ, GP1812A, and GP1812 systems come equipped with a built-in Class-D amplifier and SAT technology, allowing for even greater control over sound dispersion and ensuring precise, uniform sound in large areas. These systems cater to mid-to-large applications, such as public events, live bands, auditoriums, and nightclubs, making them perfect for both rental and permanent installations.

Portable Solutions for Smaller Events

The product range from GP8 to GP12 offers even more portability, with the GP8AB featuring a battery-powered subwoofer for versatility in any setting. Their quick setup and compact design make these systems perfect for small gigs, cocktail parties, and even karaoke sessions at home.

GPXA is our top-of-the-line high performance active system and comprises of 2x18” powered subwoofer combined with GH412, our 4x12” passive coaxial slim array with K-array™ SAT® (Slim Array Technology), PAT® (Pure Array Technology) and a stainless-steel cabinet.

Perfect for high SPL outdoor/indoor applications in large venues both for rental and permanent installations for touring, auditoriums, stadia, clubs, theme parks.

With its built-in 4x1500W RMS amplifier, this system can drive a GPX passive system in a stereo configuration. It features Powersoft™ DSP and power module, controlled via ethernet with Armonia™ control software.


Thanks to its extreme performance and the compact format of the array, this system works in a stack configuration, with the array on top of the subwoofer. It is also possible to fly GH412 with our GH-FLY flybar accessory or place it on the ground with our GH-BASE accessory.

User Tip: optimize the cost and combine the system with the passive model whether it is for stereo configurations or if need to extend the satellite cluster to form an array.

GENERAL
Power Handling: 1500W subwoofer + 750W satellite
Peak Power: 3000W subwoofer + 1500W satellite
Impedance: 4Ω subwoofer + 8Ω satellite
Frequency Range: 30Hz – 20KHz (-6dB average)
Maximum SPL (1): 140dB (peak)
Continuos SPL: 128dB
Coverage: V.30° - H.90°
AMPLIFIER
Type: 4-channel Class-D audio amplifier
Power: 4x1500W @4ohm
AC input: 100-240V AC @50-60Hz
Max power consumption: 500W Rated Load (1/8 Max Output Power)
Protections: Thermal Protections (Power limiting - Thermal Shutdown), Short-circuit/overload output protections, stationary high frequency protection, peak limiter, RMS limiter, frequency dependent RMS limiter, Clip limiter
TRANSDUCERS
 Subwoofer: 2x18” ferrite magnet
Mid High Frequency: 4x12” coaxial with 1” compression driver ferrite magnet

SUBWOOFER

 Width: 1035mm (40,75in)
Height: 614mm (24,17in)
Depth: 600mm (23,6in)
Weight: 59kg (130,07lbs)
Material: birch plywood
Rating: IP41

AUDIO I/O

Analog balanced I: 2 x Combo jack-XLR female line
Analog power O: 1 x Speakon to drive a GPX Passive System in a stereo configuration

AUDIO CONTROLS

Volume potentiometer | RJ45 connector | DSP can be remotely controlled via an Ethernet connection for control through Powersoft ArmoniaPlus Software

SATELLITE
 Width: 327mm (12,87in)
Height: 1290mm (50,79in)
Depth: 198mm (7,79in)
Weight: 55,2kg (121,69lbs)
Material: stainless steel
Rating: IP54
ACCESSORIES
 GPINM20: M20 pin (included)
K-SPKCABLE2: 2m/6,6ft Speakon sub to satellite cable (included)
GH-BASE: Floor stacking hardware for GH12/GH412 (optional)
GH-JOINT: Adjustable stacking hardware for GH12/GH412 (optional)
