The Lutron wireless repeater allows for the wireless range expansion of your Lutron lighting control system for whole house coverage.
Lutron wireless repeaters extend the range of Radio Frequency (RF) signals that are sent between devices. Up to four wireless repeaters can be added to extend the RF range for larger system applications.
Each wireless repeater has an RF range of 9m, covering an area of approximately 232m2.
It is easily added to any existing system through the Lutron App and works with RA2 Select Systems.
Expands RF range
Easily adds to an existing system through the Lutron App
Can add up to four Wireless Repeaters per system.
Works with RA2 Select systems.
Regulatory Approvals
CE
Power
5V 100mA Power Supply: 5VDC 1000mA, cable length 1.83 m Field changeable interchangeable AC plugs for United Kingdom and Europe
Typical Power Consumption
Lutron Wireless repeater: 0.45W Test Conditions: LED on, Ethernet cable plugged in, powered by the 5VDC adapter
Environment
Ambient operating temperature: 0°C / 32°F to 40°C / 104°F Relative humidity: 0% to 90% humidity, non condensing Indoor use only
Communications
All devices must be located within 9m of a repeater All repeaters must be located within 18m of another repeater
Protection
Tested to withstand electrostatic discharge without damage or memory loss in accordance with IEC 61000-4-2 Tested to withstand surge voltages without damage or loss of operation, in accordance with IEEE C62.41-1991
Power Failure Memory
Should power be interrupted, the wireless repeater will return to its previous state when power is restored
