  2. IN-LINE 16A SWITCH

IN-LINE 16A SWITCH

https://www.ced.africa/web/image/product.template/2899/image_1920?unique=7bd23cd
(0 review)

₦ 350,160.72 350160.72000000003 NGN ₦ 350,160.72

$ 204.22

Not Available For Sale

  • Colour
  • Product Type
  • Material
  • Power Consumption
  • Brand

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Colour: White
Product Type: Switches
Material: Plastic
Power Consumption: < 1.0 W
Brand: Lutron

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

The HomeWorks® PowPak range of load controllers from Lutron allow easy installation and integration for a variety of applications, simple switched controlled, 3rd party integration and analogue dimming. Complete with Lutron's Clear connect RF technology.


LMK-16R-DV-B - 16A Relay Module

The RF relay module with Softswitch is a radio frequency (RF) device that uses Lutron patented Softswitch technology to control up to 16A of general-purpose loads based on input from RA2 Select, RadioRA 2 and HomeWorks® systems.

LMK-5T-DV-B - 0 to 10V Dimming Module

The RF dimming module with 0 to 10VDC control is a radio frequency (RF) control that operates 0 to 10VDC controlled fluorescent ballasts or LED drivers based on input from RA2 Select, RadioRA 2 and HomeWorks® systems.


LMK-CCO1-24-B - Contact Closure Output Module

The RF CCO Module is a low voltage radio frequency (RF) control that provides a single dry contact closure output based on input from RadioRAR 2 and HomeWorks® QS systems. It can be powered by 24VAC of 24VDC for easy connection and integration into building management, HVAC, VAV and other 3rd party systems.

​ 16A Relay Module

  • Lutron patented Softswitch technology prevents arcing of relay contacts therefore extending product lifetime
  • Various operating voltages available.
  • Capable of switching 16A of general purpose loads
  • Operates at 220 to 240VAC
  • Utilises Lutron Clear Connect RF technology on 868MHz frequency band
  • Mounts to an electrical junction box through a 21mm / 1/2"  (trade size) knockout opening
  • Complies with requirements for use in a compartment handling environmental air (plenum) per NEC® 2011 300.22(C)(3).


0 to 10V Dimming Module

  • 0 to 10VDC control link automatically sources or sinks up to 60mA to third party fixtures
  • Switches line voltage up to 5A
  • Configurable high and low end trim
  • Operates at 220 to 240VDC
  • Utilises Lutron Clear Connect RF technology on 868MHz frequency band
  • RadioRA 2 or HomeWorks® software required for system functionality
  • Mounts to an electrical junction box through a 21mm / 1/2" knockout opening
  • Complies with requirements for use in a compartment handling environmental air (plenum) per NEC® 2011 300.22(C)(3).


Contact Closure Output Module

  • Single contact closure output including both normally open (NO) and normally closed (NC) dry contacts
  • Maintained or momentary output type
  • Operates at 24VAC or 24VDC
  • Utilises Lutron Clear Connect RF Technology on 868MHz frequency band
  • Screw tabs provided for surface mounting (recommended) or mounts to an electrical junction box through a 1/2" or 21mm trade size knockout opening
  • Complies with requirements for use in a compartment handling environmental air (plenum) per NECR 2011 300.22(C)(3)

 LMK-16R-DV-B
16A Relay Module		LMK-5T-DV-B
0 to 10V Dimming Module		LMK-CCO1-24-B
Contact Closure Output Module
Compatible WithRA2 Select, RadioRA 2 and HomeWorks systemsRA2 Select, RadioRA 2 and HomeWorks systemsRA2 Select, RadioRA 2 and HomeWorks systems
Power120 / 277V~ 50 to 60Hz 16A 0.5 HP at 120V~ 1.5 HP at 277V~ (LMJ model)
220 to 240V~ 50 to 60Hz 16A motor:
6A (LMK , LMM , LMN, LMQ models)		120 / 277V~ 50 to 60Hz 5 A (LMJ model)
220 to 240V~ 50 to 60Hz 5A (LMK, LMM, LMN, LMQ models		IEC PELV/NECR Class 2Operating voltage:
24V~ / 24V-
Operating current, nominal: 45mA (24V~), 35mA (24V-)
Typical Power Consumption< 1.0W Typical power test conditions: all loads off, top LED on< 1.0W Typical power test conditions: all loads off< 1.0W Typical power test conditions: all loads off, CCO LED on
Contact Closure Output--Accepts input voltages of 0 to 24V~ / 0 to 24V-
Resistive load: 1.0A (0 to 24V-), 0.5A (0 to 24V~)
Provides both normally open (NO) and normally closed (NC) dry contacts.
Maintained or momentary output type. Output is latching.
Minimum close time: 500ms
LoadMaximum load: 16 A general purpose.
No minimum load requirements. Load types include, but are not limited to:
Incandescent, MLV, ELV, resistive, inductive, magnetic fluorescent and electronic fluorescent		0 to10V- Control Link Maximum Load:
60 mA, source or sink automatically configures.
Control link compatible with ANSI E1.3 2001 (R2006), IEC 60929 Annex E
Switched Maximum Load: 5 A lighting.
No minimum load requirements.
Load types include, but are not limited to: MLV, ELV, incandescent, magnetic fluorescent, electronic fluorescent and LEDs		-
Surge ProtectionTested to withstand surge voltages without damage or loss of operation, in accordance with IEEE C62.41-1991 Recommended practice on surge voltages in low voltage AC power circuitsTested to withstand surge voltages without damage or loss of operation, in accordance with IEEE C62.41-1991 -
CommunicationsOperates using Clear Connect RF technology for reliable wireless communication
RF range is 9m / 30ft from repeaters		Operates using Clear Connect RF technology for reliable wireless communication
RF range is 9m / 30ft from repeaters
Recommended practice on surge voltages in low voltage AC power circuits		Operates using Clear Connect RF Technology for reliable wireless communication
RF range is 9m / 30ftfrom repeaters
Low Voltage CCO Wiring--CCO terminals accept 20 to 16 AWG (0.5 to 1.5mm2) solid or stranded wire
EnvironmentAmbient operating temperature: 0°C / 32°F to 55°C /131°F
Ambient operating humidity: 0% to 90% humidity, non condensing
Indoor use only		Ambient operating temperature: 0°C / 32°F to 40°C / 104°F
Ambient operating humidity: 0% to 90% humidity, non condensing
Indoor use only		Ambient operating temperature: 0°C / 32°F to 55°C /131°F
Ambient operating humidity: 0% to 90% humidity, non condensing
Indoor use only
MountingMounts to an electrical junction box through a 21 mm / 0.5” trade size knockout openingMounts to an electrical junction box through a 21mm / 0.5” trade size knockout openingScrew tabs provided for surface mounting (recommended) or mounts to an electrical junction box through a 21mm / 0.5” trade size knockout opening
DimensionsHeight: 87mm / 3.42”
Height incl knockout: 100mm / 3.94”
Knockout Opening: 21mm / 0.5” (trade size)
Width: 72mm / 2.82”
Depth: 32mm / 1.25”		Height: 87mm / 3.42”
Height incl knockout:100mm / 3.94”
Knockout Opening: 21mm / 0.5”
Width: 72mm / 2.82”
Depth: 32mm/ 1.25”		Height: 87mm / 3.42”
Height incl knockout: 100mm / 3.94”
Knockout Opening: 21mm / 0.5”
Width: 72mm / 2.82”
Depth: 32mm / 1.25”

Regulatory ApprovalsUL®, UL 2043 Plenum rated, FCC approved.
Complies with the limits for a Class B device, pursuant to Part 15 of the FCC rules:
CSA, IC, NOM, ANATEL (LMJ model)
CE, TRA, CITC (LMK model)
WPC (LMN model)		cULusR, UL 2043 Plenum rated, FCC approved.
Complies with the limits for a Class B device, pursuant to Part 15 of the FCC rules:
IC, NOM, ANATEL (LMJ model)
CE, TRA, CITC (LMK model)
WPC (LMN model)		ULR, UL 2043 Plenum rated, FCC approved.
Complies with the limits for a Class B device, pursuant to Part 15 of FCC rules, IC, (LMJ model only), CE, TRA, CITC (LMK model
