Lutron's Occupancy Sensor is a Radio Powr Savr sensors, which automatically turn lights on when you walk into a room and off when you leave. Available in corner mount options for the right amount of coverage in any room.
This sensor comes in white.
Go green with Radio Powr Savr. Wasted lighting can account for a majority of a building’s total energy usage. With many building spaces remaining unoccupied for 40% to 70% of the day, lights left on are a real energy drain. Lutron wireless occupancy/vacancy sensors automate the switching and dimming of those lights, saving energy and money.
It’s also convenient. You won’t have to worry about turning lights on or off anymore. Lutron occupancy/vacancy sensors automatically do the job for you every time you enter or exit an office, classroom, conference room or hallway.
Going wireless eliminates the need for costly new wiring. Radio Powr Savr sensors by Lutron install in as little as 15 minutes (default setting) and communicate with compatible Lutron dimmers, switches and light control systems using reliable Clear Connect RF Technology, which ensures a smooth and consistent performance.
You can use a mixture of ceiling, wall, corner and hallway sensors in the same system
One sensor should be sufficient for most small to medium sized rooms
There is a default 15 minute timeout after the last detected motion, which can be changed to a minimum one minute timeout
The battery will last approximately 10 years under normal use, assuming activity occurs 10 hours a day, 7 days a week
The sensor features an indicator to alert the user that the battery power is low.
The sensor uses one CR123 lithium batteries.
Power and Performance
Operating voltage: 3V Operating current: 14 μA nominal Requires one CR 123 lithium battery 10 year battery life design Non volatile memory (saved changes are stored during power loss)
RF Range
Distance between local load controls and sensor should not exceed 18m / 60ft line of sight or 9m / 30ft through walls
Sensor Coverage Test
Front accessible test button Lens illuminates orange in response to motion during test mode and is visible from 18m / 60ft
Wireless Communication Test
Front accessible test button Turn associated loads on and off
Timeout Options
1 minute (intended for use in high activity, briefly occupied areas only) 5 minutes 15 minutes (default setting) 30 minutes
Sensitivity Options
Low activity (default setting) Medium activity High activity
Environment
Temperature: 0°C / 32°F to 40°C / 104°F Relative humidity: less than 90% non condensing For indoor use only
Dimensions
Height: 90.7mm / 3.57" Depth: 28.7mm / 1.13"
Regulatory Approval
CE marked (European Union) TRA type approved CITC type approved
