Ruijie - Indoor Access Point (E)

https://www.ced.africa/web/image/product.template/1799/image_1920?unique=3284ac9
(0 review)

Dual-band ceiling mount Access Point is a high-performance ceiling mount Access Point.[MOQ: 10pcs]

₦ 197,456.22 197456.22 NGN ₦ 197,456.22

$ 115.16

Not Available For Sale

  • Product Type
  • Power Consumption
  • Wireless Protocol
  • Network Port
  • Recommended Clients
  • Power Supply
  • Client Capacity
  • Protocol

This combination does not exist.

Out of Stock
Invalid email
We'll notify you once the product is back in stock.
Contact Us
Product Type: Wireless
Power Consumption: <12.95W
Wireless Protocol: 802.11ac Wave2, 1267Mbps
Network Port: 1 x 10/100/1000M/2.5G Base-T, 1 x 10/100/1000 Base-T
Recommended Clients: 80
Power Supply: 802.3af/at PoE, 12V/1.5A DC Adaptor
Client Capacity: 110
Protocol: 802.11ac Wave2

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Ruijie - Indoor Access Point (E)

Ruijie Reyee Series RG-RAP2200 Series dual-band ceiling mount AP is a high-performance ceiling mount AP for indoor large-area Wi-Fi coverage scenarios.

RG-RAP2200 Series is an ideal choice for scenarios with simple building structure, no special obstructions, and relatively concentrated users, such as conference rooms, libraries, classrooms, bars, leisure centers, etc. The AP can be flexibly implemented according to different environments, and provides user access for up to 110 terminals per AP.

Ruijie Reyee Series RG-RAP2200 Series dual-band ceiling mount AP is a high-performance ceiling mount AP for indoor large-area Wi-Fi coverage scenarios. The device supports 802.3af/at PoE and 12V DC local power supply. The dual LAN ports design facilitates the expansion of third-party devices to meet the needs of more networking scenarios. Compliant with 802.11a/b/g/n/ac Wave1/Wave2 Wi-Fi protocol, RG-RAP2200 supports MU-MIMO dual-stream technology and offers built-in omnidirectional antennas. It can operate concurrently at 2.4GHz and 5GHz, providing high-speed wireless access of 400Mbps at 2.4GHz, 867Mbps at 5GHz and up to 1267Mbps per AP. Its coverage of over 20 meters makes it an ideal choice for many wireless scenarios, especially in offices, commercial industry, hotels, service scenarios, etc.


Users can perform comprehensive local management or remote management of the equipment in the entire network via the Ruijie Cloud app, equipment EWEB management, Ruijie Cloud platform, etc. Users can also share the network to third party for network hosting and collaborative management, thereby achieving simpler, easier to use, more secure and convenient enterprise network operation and maintenance.

The industrial product design, iconic edges and breathing light makes the product more recognizable. Adopting the non-directional installation design, the new mounting kits support various installation methods including on desktop, ceiling, wall, and pole, which improves the versatility of installation, simplifies the installation steps, reduces the installation difficulty, and greatly improves the installation experience of the device.


RG-RAP2200 Series supports Ruijie’s self-developed smart networking feature. With the Ruijie Cloud app, users can quickly complete the device deployment and configuration, remote management, operation and maintenance of the entire network, which greatly reduces the investment of equipment cost, labor cost and time cost in the process of wireless network construction.

​

High-speed dual-band Wi-Fi

The device supports 2.4GHz and 5GHz dual-band communication, providing access rate of 400Mbps at 2.4GHz, 867Mbps at 5GHz and up to 1267Mbps per AP. It can provide 5GHz frequency band with less interference, wider channel, and faster speed for the terminals, allowing the users to enjoy excellent wireless experience.

Dual LAN ports design

The device adopts the dual LAN ports design. Even for complex networking requirements, it can easily and quickly support the expansion of third-party devices, such as cameras, time and attendance devices, etc.

Support routing and AP mode

The device supports both AP and routing mode. A wireless network can be formed with multiple APs, or it can be used as a wireless router when deployed independently. The device offers more flexible configurations, more abundant application features, and more extensive applicable scenarios.

Support Layer 3 roaming

The device supports Layer 3 roaming for the complex Layer 3 network. When users move across the Layer 3 networks, seamless roaming can be achieved without service interruption. Stronger and more stable signals An aluminum alloy antenna reflector is added to reflect interference signals and focus effective signals so as to provide stronger signal transmission and better receiving sensitivity. The device uses FBAR to filter out most of interferences caused by the operator's base stations, microwave ovens, Bluetooth devices, etc., so as to provide cleaner wireless signals, higher transmission rate and more stable transmission quality.  Robust casing With the robust and flame-retardant material of the AP casing, the impact resistance is 5 times higher than that of common ABS plastic materials. The tensile and flexural strengths are increased by 30%, which is not easy to damage. Users can rest assured during usage and maintenance.  Simple installation It supports various installation methods including on desktop, ceiling, wall, and pole. Adopting the non-directional installation design, the equipment can be installed in one go efficiently.  Industrial design The industrial product design, iconic edges and breathing light makes the product more recognizable.


Model

RG-RAP2200(E)

RG-RAP2200(F)

Hardware specifications

Radio

Dual-stream dual-band

Protocol

Concurrent 802.11ac wave2, wave1, 802.11a/b/g/n

Operating Bands

802.11b/g/n ：2.4G ~ 2.4835GHz

802.11a/n/ac ： 5G：5.150～5.250GHz，5.725～5.850GHz (country specific)

Antenna

Internal antennas（2.4G: 2dBi，5G: 2dBi）

Spatial Streams

2.4G 2x2MIMO  5G 2x2MIMO

Max Throughput

Up to 400Mbps at 2.4G

Up to 867Mbps at 5G

1.267Gbp per AP

Modulation

OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps

DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps

MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM

Receive Sensitivity

11b: -91dBm (1Mbps), -88dBm (5Mbps), -85dBm (11Mbps)

11a/g: -89dBm (6Mbps), -80dBm (24Mbps), -76dBm (36Mbps), -71dBm (54Mbps)

11n: -83dBm@MCS0, -65dBm@MCS7, -83dBm@MCS8, -65dBm@MCS15

11ac HT20: -83dBm (MCS0), -57dBm (MCS9)

11ac HT40: -79dBm (MCS0), -57dBm (MCS9)

11ac HT80: -76dBm (MCS0), -51dBm (MCS9)

Maximum Transmit Power

5.725～5.850GHz：≤20dBm (EIRP)

5.150～5.250GHz：≤20dBm (EIRP)

2.4～2.4835GHz：≤20dBm (EIRP)

Adjustable Power

1dBm

1dBm

Dimensions

194mm×194mm×35mm (excluding mounting kits)

194mm×194mm×35mm (excluding mounting kits)

Weight

0.45kg (excluding mounting kits)

0.45kg (excluding mounting kits)

Service Ports

2 10/100/1000Base-T Ethernet ports, PoE/LAN1 port supports PoE

2 10/100Base-T Ethernet ports,

PoE/LAN1 port supports PoE

Management Port

NA

NA

LED Indicator

NA

NA

Power Supply

Single indicator (green light)

Power Consumption

Local power supply, DC 12V/1.5A (Note: The power adapter is sold as an optional accessory)

802.3af/802.3at PoE

Environment

≤ 12.95W

Operating temperature: 0°C～40°C

Storage temperature: -40°C～70°C

Operating humidity: 5％～95％（non-condensing）

Installation

Storage humidity: 5％～95％（non-condensing）

Safety Standard

GB4943, IEC 62368-1

EMC Standard

GB9254，EN301 489，EN50155，EN50121，EN55032，EN61000，EN55035

Vibration Standard

IEC61373

Radio Standard

EN300 328, EN301 893

MTBF

>250000H

>250000H

Software Features



Operating Mode

AP mode and routing mode

WLAN

Maximum number of clients: 110

Recommended number of clients: 80 (16 at 2.4GHz, 64 at 5GHz)

Recommended number of clients: 48 (16 at 2.4GHz, 32 at 5GHz)

Up to 8 SSIDs

Support SSID hiding

Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID

SSID-based and radio-based STA limit

Support Layer 2 user isolation

Roaming

Support Layer 2 and Layer 3 roaming

Security

Support PSK authentication

Support static blacklist and whitelist

Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption

Routing

Support static IP address, DHCP, PPPoE Dial Up

Management and maintenance

Support unified networking of all network equipment

Support local or remote management with Ruijie Cloud app

Support local management with web

Support remote management with Ruijie Cloud platform

Platform management features

Automatic RF adjustment via the platform

Unified configuration via the platform

Unified monitoring via the platform
