The RA2 Select main repeater from Lutron allows for setup, control and monitoring of select lighting devices and Lutron wireless shades from a smartphone or tablet using the Lutron App.
This repeater supports up to 100 wireless devices, including dimmers, switches, Pico wireless controls and wireless shades. It also offers Scene control via the Lutron App and Pico scene keypads. The Lutron App additionally allows Timeclock scheduling of daily events, which means you needn't be home to do this.
The main repeater and additional wireless repeaters each count as one device.
It is programmed via the Lutron App, which is available for iOS® and AndroidTM).
This repeater offers the added benefit of connecting to the Wi Fi router via an ethernet connection and local device operation will continue to function even if internet connection is lost or if the main repeater is powered down or not communicating.
Up to 4 wireless repeaters (LK-REPPRO-BL) can be added to extend the range for larger systems.
upports up to 100 wireless devices, including dimmers, switches, Pico wireless controls and wireless shades. The main repeater and additional wireless repeaters each count as one device
Programmed via the Lutron App (available for iOS® and AndroidTM)
Scene control via the Lutron App and Pico scene keypads
Timeclock scheduling of daily events via the Lutron App
Connects to the Wi Fi router via an ethernet connection
Local device operation will continue to function even if internet connection is lost or if the main repeater is powered down or not communicating
System access from anywhere in the world using the Lutron App
Control outside the app via iOSR and AndroidT
Supports Geofencing from the Lutron App
Control from Apple Watch
Supports integration with other smart home brands including Amazon® Alexa®, Google® Assistant, Nest®, Sonos® and more
Up to 4 wireless repeaters (LK-REPPRO-BL) can be added to extend the range for larger systems. (See additional information on the Download Tab)
Automatically programs Pico wireless controls for typical applications and activities or program additional custom scenes using the Lutron App
Integration with select professional A/V and security systems
Regulatory Approvals
CE
Power
5 V- 300 mA Power Supply: 5 VDC 1000 mA, cable length 1.83m Field changeable interchangeable AC plugs for United Kingdom and Europe
Typical Power Consumption
RA2 Select main repeater: 1.3 W Test Conditions: LED on, Ethernet cable plugged in, powered by the 5 VDC adapter
Environment
Ambient operating temperature: 0 °C to 40 °C 0% to 90% humidity, non condensing Indoor use only
Communications
All devices must be located within 9 m of a repeater All repeaters must be located within 18 m of another repeater Internet connection required for initial setup, to maintain system date/time and receive periodic firmware updates
Protection
Tested to withstand electrostatic discharge without damage or memory loss in accordance with IEC 61000-4-2 Tested to withstand surge voltages without damage or loss of operation, in accordance with IEEE C62.41-1991
Power Failure Memory
Should power be interrupted, the RA2 Select main repeater will return to its previous state when power is restored
Connections
Ethernet: 0.92 m cable included (for internet and Lutron App connection)
